- ClimaTek 8" Chrome Burner Drip Pan Bowl Replaces Whirlpool # 7-0441 580037 5-80037 4381751 4371751
Product Description
SPECS:
Range/Cooktop/Stove chrome drip pan. 8.25" in diameter. 1.25" height. Center hole measures 2" in diameter.
COMPATIBLE WITH THESE BRANDS:
Whirlpool Estate KitchenAid Roper Maytag Admiral Amana Speed Queen Jenn-Air Magic Chef Crosley Caloric Glenwood Hardwick Menumaster Modern Maid Montgomery Wards Norge JC Penney Wards Sears Kenmore
OEM / AFTERMARKET:
Aftermarket
DESCRIPTION:
Drip pans have a purpose beyond looking attractive. Drip pans capture and reflect heat back to the coil which makes the burner work more efficiently. Drip pans also catch spills that otherwise would drip down into the internal workings of the stove and can prevent electric shock to the user. With regular use, drip pans do become discolored with time and may have to be replaced. Helpful Note: Aluminum foil is not a safe alternative for a drip pan. The heat beneath a range top element can reach upwards of 1000 degrees F which can ignite the aluminum foil, damage the range top and put you at risk for injury.
REPLACES PART NUMBERS:
715878 Y700441 715029 700441 7-15878 7-15029 7-0441 580037 5-80037 4381751 4371751
USED ON MODELS:
