- ClimaTek 6" Burner Replaces Whirlpool # 4164222 403870 403512 325510 325510 325507 321014 319266
Product Description
SPECS:
This heavy duty 6" burner element has 4 turns/rings and has a heavy duty D-Frame structure to support the element. This burner element is rated at 1500 watts. The wire looped terminals have been replaced with these solid terminals. This element also replaces some flat style terminal elements.
COMPATIBLE WITH THESE BRANDS:
Whirlpool Estate KitchenAid Roper Maytag Admiral Amana Speed Queen Jenn-Air Magic Chef Crosley Caloric Glenwood Hardwick Menumaster Modern Maid Montgomery Wards Norge JC Penney Wards Sears Kenmore
OEM / AFTERMARKET:
Aftermarket
DESCRIPTION:
The surface burner elements, those metal components that get red-hot and generate heat, are the most important parts of any range. When the elements fail to heat properly, it's time to replace them. It's a simple procedure any electric stove owner can easily accomplish in a few minutes' time. You can usually identify a burnt-out element by blistering or small holes on the element's coils. A burner that plugs into a receptacle is easy to test, just unplug the non-heating burner, plug it into another working receptacle, restore the power to the range, and test it. If the burner works, you know its original receptacle is probably faulty. If it doesn??t work in the good receptacle, the burner is bad and must be replaced. Do not be alarmed if a new element smokes a little when you first use it. This is a factory-applied green coating, that prevents scratches during shipment, burning away.
REPLACES PART NUMBERS:
326787 4164222 403870 403512 325510 325510 325507 321014 319266 318580 312557 306667 306666 306665 306664 303251 301412 299685 299466 263901 263893 263569 263564 263563 263558 263375 263146 263140 263090 256804 256803 256699 256698 256697 256696 244963 244957 244948 244146 244145 244062 244058 244012 242417 241742 241418 241417 241416 236140 14210966
USED ON MODELS:
1303^0A 1303W0A 1433^0A 1433^1A 1433^2A 1433W0A 1433W1A 1433W2A 1453^0A 1453W0A 1463W0A 1463W1A 1463W2A 1743W0A 1833^0A 1833W0A 2216*00 2216*10 2216*20 2216W00 2216W10 2216W20 2236*00 2236*10 2236*20 2236W00 2236W10 2236W20 2413*0A 2413W0A 2453*9A 2453*AA 2453W9A 2453WAA 2454X0A 2454X1A 2454X2A 2454X3A 2496*0 2496*0A 2496*1 2496*1A 2496*2 2496*2A 2496X0 2496X1 2496X2 C3357^0 D5257*2 D5257X0 D5257X2 D5757*0 D5757X0 D9757*5 D9757*6 D9757^1 D9757W5 D9757W6 F5007*1 F5007W1 F5108*0 F5108W0 F5907W0 F5908W0 F7107*1 F7107W1 F7108*0 F7108W0 F7907W0 F7908W0 F9157*1 F9157W1 F9257*0 F9257*1 F9257W0 F9257W1 F9757*1 F9757W1 F9858*0 F9858W0 KECG260SWH1 KECS-1040WH KECS100SWH0 KECS100SWH1 KECS1040WH KECS160SWH0 KECX160SWH0 KECX260SWH1 LSE2700W LSE2700W-8 LSE2700W-C LSG2700W N3157*1 N3157W1 N3257*1 N3257W1 N9157*0 N9157*1 N9157L0 N9157L1 N9157X0 N9257*0 N9257*1 N9257*2 N9257L1 N9257L2 N9257X0 N9257X1 N9357*0 N9357*2 N9357*3 N9357L0 N9357L2 N9357L3 N9457*2 N9457*3 N9457*4 N9457*5 N9457L3 N9457X2 N9457X3 N9457X4 N9457X5 RC8536XTW0 RE953PXKT0 RE953PXPT0 RE953PXPT1 RE960PXKW0 RE960PXKW1 RE960PXKW2 RE960PXPW0 RE960PXPW1 RE963PXKT0 RE963PXKT1 RE963PXPT0 RE963PXPT1 RF0100XKW0 RF0100XKW1 RF010ESPW0 RF010EXPW0 RHM973PP0 RHM975PW RHM975PW1 RHM988PW RHM988PW1 RM955PXKW0 RM955PXLW0 RM955PXLW1 RM955PXLW2 RM955PXPW0 RM973BXPT0 RM973PXKT0 RM973PXLT0 RM973PXLT1 RM973PXLT2 RM975PXKG0 RM975PXKN0 RM975PXKW0 RM975PXLW0 RM975PXLW1 RM975PXLW2 RM978BXPW0 RM988PXKW0 RM988PXLW0 RM988PXLW2 RM988PXLW9 RM988PXPW0 RS3025XBN0 RS3025XBN1 RS3025XBW0 RS3025XBW1 RS310PXBH0 RS310PXEB0 RS310PXEB1 RS385PCBN0 RS385PCBW0 RS385PXBH0 RS385PXBQ0 RS385PXEB0 RS385PXEB1 RS385PXEQ0 RS385PXEQ1 S5007W0 S9507*2 S9507W2
