SPECS:
Range/Cooktop/Stove Chrome drip bowl. 7.5" in diameter. 1.75" height. Center hole measures 2.25" in diameter.
COMPATIBLE WITH THESE BRANDS:
GE General Electric Hotpoint RCA Sears Kenmore
OEM / AFTERMARKET:
Aftermarket
DESCRIPTION:
Drip bowls have a purpose beyond looking attractive. Drip bowls capture and reflect heat back to the coil which makes the burner work more efficiently. Drip bowls also catch spills that otherwise would drip down into the internal workings of the stove and can prevent electric shock to the user. With regular use, drip bowls do become discolored with time and may have to be replaced. Helpful Note: Aluminum foil is not a safe alternative for a drip pan. The heat beneath a range top element can reach upwards of 1000 degrees F which can ignite the aluminum foil, damage the range top and put you at risk for injury.
REPLACES PART NUMBERS:
WB31K5024 WB62K5084 WB31K5024E 345807 345807 345002
USED ON MODELS:
3636244190 3636424190 3639114190 3639144190 3639164190 3639321191 3639324190 3639324590 3639330193 3639334190 3639354190 3639354590 JBP15GIT1WH JBP15GIV1WH JBP18LY1WH JBP23BY1AD JBP23BY1WH JBS02LY1WH JBS02LY2WH JBS05Y1AD JBS05Y1WH JBS05Y2AD JBS05Y2WH JBS23BY1AD JBS23BY1WH L3B115GL1 L3B115GL2 L3B115GL3 L3B130GL1 L3B130GL2 L3B130GL3WH L3B150GL1 L3B150GL2 L3B315GL1 L3B315GL2 L3B325GL2 L3B325GL3 L3B325GL4 L3B345GL1 L3B345GL2
