ClimaTek Range Stove Cooktop 6" Burner Kit Replaces GE Hotpoint Kenmore # PM30X120 PM30X0120

Price: $32.95

Quantity:

Product Description


SPECS:
High rise surface element kit with tilt lock hinge. This 2 wire 6" burner element has 5 turns/rings and has a Y-Frame structure to support the element. This burner element is rated at 1350 watts. Includes terminal receptacle block and all necessary hardware. Does not include attached trim ring.
COMPATIBLE WITH THESE BRANDS:
GE General Electric Hotpoint RCA Sears Kenmore
OEM / AFTERMARKET:
Aftermarket
DESCRIPTION:
The surface burner elements, those metal components that get red-hot and generate heat, are the most important parts of any range. When the elements fail to heat properly, it's time to replace them. It's a simple procedure any electric stove owner can easily accomplish in a few minutes' time. You can usually identify a burnt-out element by blistering or small holes on the element's coils. A burner that plugs into a receptacle is easy to test, just unplug the non-heating burner, plug it into another working receptacle, restore the power to the range, and test it. If the burner works, you know its original receptacle is probably faulty. If it doesn??t work in the good receptacle, the burner is bad and must be replaced. Do not be alarmed if a new element smokes a little when you first use it. This is a factory-applied green coating, that prevents scratches during shipment, burning away.
REPLACES PART NUMBERS:
WB30X359 WB30X359R WB30X0359 PM30X120 PM30X0120
USED ON MODELS:
JAS01*J1 JAS01*J2 JAS01*J3 JAS01*J4 JAS01*J5 JAS03*H1 JBC16G*H1 JBC16G*J1 JBC16G*J2 JBC16G*J3 JBC16G*K1 JBC16G*K2 JBC16G*N1 JBC16G*N2 JBC16G*P1 JBC16G*P2 JBP22*F1 JBP22*F2 JBP22*F3 JBP22*J1 JBP22*J2 JBP22*J3 JBP22*J4 JBP22*K1 JBP22*K2 JBP22*N1 JBP22*N2 JBP22*P1 JBP22G*J1 JBP22G*J2 JBP22G*K1 JBP22G*K2 JBP22G*N1 JBP22G*N2 JBP22G*P1 JBP22G*P2 JBP22GK1 JBP22GK2 JBP22K1 JBP22K2 JBS02*J1 JBS02*J2 JBS02*J3 JBS02*N1 JBS02*N2 JBS02*P1 JBS03*06 JBS03*J1 JBS03*J2 JBS03*J3 JBS03*K1 JBS03*N1 JBS03*N2 JBS03*P1 JBS030J3 JBS034K1 JBS034N1 JBS034P1 JBS03G*H1 JBS03G*J1 JBS03G*J2 JBS03G*J3 JBS03G*K1 JBS03G*K2 JBS03G*N1 JBS03G*N2 JBS03G*P1 JBS03G*P2 JBS03G0J3 JBS03GK1 JBS03GK2 JBS03GN1 JBS03K1 JBS03N1 JBS03N2 JBS03P1 JBS16*J1 JBS16*J2 JBS16*J3 JBS16*K1 JBS16*K2 JBS16*N1 JBS16*N3 JBS16*P1 JBS16G*H1 JBS16G*J1 JBS16G*J2 JBS16G*J3 JBS16G*K1 JBS16G*K2 JBS16G*N1 JBS16G*N2 JBS16G*P1 JBS16G*P2 JBS16P1 JBS21G*H1 JBS21G*J1 JBS21G*J2 JBS21G*J3 JBS21G*K1 JMC27G*H1 JMC27G*J1 JMC27G*J2 JMC27G*J3 JMC27G*J4 JMC27G*J5 JMC27G0J3 JMC27GJ4 JMP26G*H1 JMP26G*J1 JMP26G*J2 JMP26G*J3 JMP26G*J4 JMP26G*J5 JMP26G0J3 JMP26GJ4 JMP26GJ5 JMS07*J1 JMS07*J2 JMS07*J3 JMS07*J4 JMS07*J5 JMS070J3 JMS07G*P1 JMS07J4 JMS07J5 JMS27G*H1 JMS27G*J1 JMS27G*J2 JMS27G*J3 JMS27G*J4 JMS27G0J3 JMS27GJ4 JP651*C1 JP651*J1 JP651*J2 JP6510J2 JP651B*C1 JP651B*J1 JP651B*J2 JP651B0J2 JP651B9C1 JSC27G*04 JSC27G*05 JSC27G*06 JSC27G*H1 JSC27G*J1 JSC27G*J2 JSC27G*J3 JSC27G*J4 JSC27G*J5 JSC27G*J7 JSC27G0J3 JSP23*02 JSP27*02 JSP27*05 JSP27*D3 JSP27*J1 JSP27*J2 JSP27*J3 JSP27*J4 JSP27*J5 JSP27*J6 JSP27J4 JSP27J5 JSP27J6 JSP28G*02 JSP28G*05 JSP28G*D1 JSP28G*D3 JSP28G*H1 JSP28G*H2 JSP28G*J1 JSP28G*J2 JSP28G*J3 JSP28G*J4 JSP28G*J5 JSP28G*J6 JSP28G*J7 JSP28GJ4 JSP28GJ5 JSP28GJ6 JSP28GJ7 JSS01*01 JSS01*02 JSS01*03 JSS01*04 JSS01*J1 JSS01*J2 JSS01*J3 JSS26*03 JSS26*04 JSS26*05 JSS26*J1 JSS26*J2 JSS26*J3 JSS26*J4 JSS26*J6 JSS26J4 JSS26J6 JSS27G*03 JSS27G*04 JSS27G*05 JSS27G*H1 JSS27G*J1 JSS27G*J2 JSS27G*J3 JSS27G*J4 JSS27G*J5 JSS27G*J7 JSS27G0J3 JSS27GJ4 JSS27GJ5 JSS27GJ7 RA511*J1 RA511*J2 RA511*J3 RA511*J4 RA511*J5 RA513*J1 RA513*J2 RA513*J3 RA513*J4 RB524*J1 RB524*J2 RB524*J3 RB524*N1 RB524*P1 RB525*J1 RB525*J2 RB525*J3 RB525*J4 RB525*N1 RB525*N2 RB525*N3 RB525G*H1 RB525G*J1 RB525G*J2 RB525G*J3 RB525G*J4 RB525G*J5 RB525G*J6 RB525G*N1 RB525G*N2 RB525G*N3 RB532G*H1 RB532G*J1 RB532G*J2 RB532G*J3 RB532G*J4 RB532G*J5 RB532G*J6 RB532G*N1 RB532G*N2 RB532G*N3 RB632G*H1 RB632G*J1 RB632G*J2 RB632G*J3 RB632G*J4 RB632G*J5 RB632G*J6 RB632G*N1 RB632G*N2 RB632G*N3 RB734*A6 RB734*J1 RB734*J2 RB734*J3 RB734*J4 RB734*J5 RB734*J6 RB734*J7 RB734*J8 RS42*02 RS42*J1 RS42*J2 RS42*J3 RS42*J4 RS42*J5 RS42*J6 RS46*03 RS46*04 RS46*J1 RS46*J2 RS46*J3 RS46*J4 RS46*J5 RS46*J7 RS47G*03 RS47G*04 RS47G*H1 RS47G*J1 RS47G*J2 RS47G*J3 RS47G*J4 RS47G*J5 RS47G*J6 RS647G*05 RS647G*H1 RS647G*J1 RS647G*J2 RS647G*J3 RS647G*J4 RS647G*J5 RS647G*J6 RS647G*J8 RS742*02 RS742*03 RS742*04 RS742*06 RS742*J1 RS742*J2 RS742*J3 RS742*J4 RS742*J5 RS742*J6 RS742*J8 RS743G*02 RS743G*03 RS743G*04 RS743G*06 RS743G*H1 RS743G*J1 RS743G*J2 RS743G*J3 RS743G*J4 RS743G*J5 RS743G*J6 RS743G*J8
